PowerFlex 400 Adjustable Frequency AC Drive Quick Start English-23
A182 [Drive OL Mode] 0/3 0 = “Disabled”
1 = “Reduce CLim”
2 = “Reduce PWM”
3 = “Both-PWM 1st
3
A183 [SW Current Trip] 0.0/(Drive Amps × 1.8) 0.1 Amps 0.0 (Disabled)
A184 [Load Loss Level] 0.0/Drive Amps 0.1 Amps 0.0 (Disabled)
A185 [Load Loss Time] 0/9999 Secs 1 Secs 0 (Disabled)
A186 [Stall Fault Time] 0/5 0 = “60 Seconds”
1 = “120 Seconds”
2 = “240 Seconds”
3 = “360 Seconds”
4 = “480 Seconds”
5 = “Flt Disabled”
0
A187 [Bus Reg Mode] 0/1 0 = “Disabled” 1 = “Enabled” 1
A188 [Skip Frequency 1] 0/320 Hz 1 Hz 0 Hz
A189 [Skip Freq Band 1] 0.0/30.0 Hz 0.1 Hz 0.0 Hz
A190 [Skip Frequency 2] 0/320 Hz 1 Hz 0 Hz
A191 [Skip Freq Band 2] 0.0/30.0 Hz 0.1 Hz 0.0 Hz
A192 [Skip Frequency 3] 0/320 Hz 1 Hz 0 Hz
A193 [Skip Freq Band 3] 0.0/30.0 Hz 0.1 Hz 0.0 Hz
A194 [Compensation] 0/3 0 = “Disabled”
1 = “Electrical”
2 = “Mechanical”
3 = “Both”
3
A195 [Reset Meters] 0/2 0 = “Ready/Idle” 1 = “Reset MWh”
2 = “Reset Time”
0
A196 [Testpoint Sel] 1024/65535 1 1024
A197 [Fault Clear] 0/2 0 = “Ready/Idle” 1 = “Reset Fault”
2 = “Clear Buffer”
0
A198 [Program Lock] 0/3 0 = “Unlocked”
1 = “Locked” (All)
2 = “Locked” (Not Network)
3 = “Locked” (P035, A170)
0
A199 [Motor NP Poles] 2/40 1 4
A200 [Motor NP FLA] 0.1/(Drive Amps × 2) 0.1 Amps Rated Amps
No. Parameter Min/Max Display/Options Default
Aux Relay Card Group Parameters
No. Parameter Min/Max Display/Options Default
R221
R224
R227
R230
R233
R236
[Relay Out3 Sel]
[Relay Out4 Sel]
[Relay Out5 Sel]
[Relay Out6 Sel]
[Relay Out7 Sel]
[Relay Out8 Sel]
0/23 0 = “Ready/Fault”
1 = “At Frequency”
2 = “MotorRunning”
3 = “Hand Active”
4 = “Motor Overld”
5 = “Ramp Reg”
6 = “Above Freq”
7 = “Above Cur”
8 = “Above DCVolt”
9 = “Above Anlg 2”
10 = “Above PF Ang”
11 = “Anlg In Loss”
12 = “ParamControl”
13 = “Retries Exst”
14 = “NonRec Fault”
15 = “Reverse”
16 = “Logic In 1”
17 = “Logic In 2”
23 = “Aux Motor”
0
R222
R225
R228
R231
R234
R237
[Relay Out3 Level]
[Relay Out4 Level]
[Relay Out5 Level]
[Relay Out6 Level]
[Relay Out7 Level]
[Relay Out8 Level]
0.0/9999 Hz 0.1 0.0
R239 [Aux Motor Mode] 0/1 0 = “Disabled” 1 = “Enabled” 0
R240 [Aux Motor Qty] 1/6 1 = “1 Aux Mtr”
2 = “2 Aux Mtr”
3 = “3 Aux Mtr”
4 = “1 Mtr + Swap
5 = “2 Mtr + Swap
6 = “3 Mtr + Swap
1
R241
R244
R247
[Aux 1 Start Freq]
[Aux 2 Start Freq]
[Aux 3 Start Freq]
0.0/320.0 Hz 0.1 Hz 50.0 Hz
[Relay OutX Select] Setting [Relay OutX Level] Min/Max
6 0/320 Hz
7 0/180%
8 0/815 Volts
9 0/100%
10 1/180 degs
12 0/1
