English-6 PowerFlex 400 Adjustable Frequency AC Drive Quick Start
Category Specification
Agency
Certification
Listed to UL508C and CAN/CSA-22.2
Listed to UL508C for plenums
Certified to AS/NZS, 1997 Group 1, Class A
Marked for all applicable European Directives
EMC Directive (89/336)
EN 61800-3, EN 50081-1, EN 50082-2
Low Voltage Directive (73/23/EEC)
EN 50178, EN 60204
The drive is also designed to meet the appropriate portions of the following specifications:
NFPA 70 - US National Electrical Code
NEMA ICS 3.1 - Safety standards for Construction and Guide for Selection, Installation and
Operation of Adjustable Speed Drive Systems.
IEC 146 - International Electrical Code.
Protection Bus Overvoltage Trip: 200-240V AC Input: 405V DC bus voltage (equivalent to 290V AC
incoming line)
380-460V AC Input: 810V DC bus voltage (equivalent to 575V AC
incoming line)
Bus Undervoltage Trip: 200-240V AC Input: 210V DC bus voltage (equivalent to 150V AC
incoming line)
380-480V AC Input: 390V DC bus voltage (equivalent to 275V AC
incoming line)
Power Ride-Thru: 100 milliseconds
Logic Control Ride-Thru: 0.5 seconds minimum, 2 seconds typical
Electronic Motor Overload
Protection:
Provides class 10 motor overload protection according to NEC
article 430 and motor over-temperature protection according to
NEC article 430.126 (A) (2). UL 508C File 29572.
Overcurrent: 180% hardware limit, 220% instantaneous fault
Ground Fault Trip: Phase-to-ground on drive output
Short Circuit Trip: Phase-to-phase on drive output
Electrical Efficiency: 97.5% at rated amps, nominal line voltage
Control
Output Frequency: 0-320 Hz (programmable)
Control
Inputs
Digital: Quantity: (3) Semi-programmable
(4) Programmable
Type
Source Mode (SRC):
Sink Mode (SNK):
18-24V = ON, 0-6V = OFF
0-6V = ON, 18-24V = OFF
Analog: Quantity: (1) Isolated, –10 to 10V or 4-20mA
(1) Non-isolated, 0 to 10V or 4-20mA
Specification
Resolution:
0 to 10V DC Analog:
4-20mA Analog:
External Pot:
10-bit
100k ohm input impedance
250 ohm input impedance
1-10k ohm, 2 Watt minimum
Control
Outputs
Relay: Quantity: (2) Programmable Form C
Specification
Resistive Rating:
Inductive Rating:
3.0A at 30V DC, 3.0A at 125V, 3.0A at 240V AC
0.5A at 30V DC, 0.5A at 125V, 0.5A at 240V AC
Optional
Relay
Card:
Quantity: (6) Optional Programmable Form A (Drive Frames D, E & F Only)
Specification
Resistive Rating:
Inductive Rating:
0.1A at 30V DC Class II circuits, 3.0A at 125V,
3.0A at 240V AC
0.1A at 30V DC Class II circuits, 3.0A at 125V
3.0A at 240V AC
Opto: Quantity:
(1) Programmable
Specification: 30V DC, 50mA Non-inductive
Analog: Quantity: (2) Non-Isolated, 0-10V or 4-20mA
Specification
Resolution:
0 to 10V DC Analog:
4-20mA Analog:
10-bit
1k ohm minimum
525 ohm maximum
