PowerFlex 4M Adjustable Frequency Drive FRN 1.xx - 2.xx User Manual
Publication 22F-UM001D-EN-E
Index
A
AC Supply
Ground, 1-5
Source, 1-3
Ungrounded, 1-3
Advanced Program Group
P
arameters, 3-19
Ambient Temperatures, 1-2
Armored Cable, 1-10
Auto Rstrt Tries Fault, 4-4
Auxiliary Input Fault, 4-3
B
Before Applying Power, 2-1, 2-2
C
Cable Length, 1-13
Cable, Power, 1-9
Catalog Number Explanation, P-4
CE Conformity, 1-21
Checklist, Start-Up, 2-1, 2-2
Circuit Breakers
Input, 1-7
Comm Loss Fault, 4-4
Command Sources for Start and
Spee
d, 1-19
Communications Group Parameters,
3-17
Contactors, Input, 1-12
Control, 2 and 3 Wire, 1-15, 1-18
Conventions, Manual, P-2
Cover, Opening, 1-1
Cross Reference, Parameter
by Name, 3-31
D
Dimensions
Drive, B-6
Minimum Clearances, 1-2
Display, 2-3
Display Group Parameters, 3-3
Distribution Systems, Ungrounded,
1-3
Drive Frame Size, P-2, B-6
Drive Grounding, 1-5
Drive Overload Fault, 4-4
Drive Ratings, P-4, A-1
DriveExecutive, 3-1
DriveExplorer, 3-1
E
Earthing, see Grounding
EMC/RFI
Grounding, Filter, 1-6
Interference, 1-21
Enclosure Rating, Changing, 1-2
ESD, Static Discharge, P-3
F
Faults
Auto Rstrt Tries, 4-4
Auxiliary Input, 4-3
Comm Loss, 4-4
Drive Overload, 4-4
Ground Fault, 4-3
Heatsink OvrTmp, 4-3
HW OverCurrent, 4-3
I/O Board Fail, 4-4
Motor Overload, 4-3
Motor Stalled, 4-3
OverVoltage, 4-3
Parameter Checksum, 4-4
Phase Short, 4-4
Phase to Ground Short, 4-4
Power Loss, 4-3
Power Unit, 4-4
SW OverCurrent, 4-4
UnderVoltage, 4-3
Filter, RFI, 1-6
Frame Designations, P-2, A-1, B-6
Fuses
Input, 1-7
Ratings, A-1
