Programming and Parameters 3-21
PowerFlex 4M Adjustable Frequency Drive FRN 1.xx - 2.xx User Manual
Publication 22F-UM001D-EN-E
Advanced Program Group (continued)
A410 [Preset Freq 0]
(1)
A411 [Preset Freq 1]
A412 [Preset Freq 2]
A413 [Preset Freq 3]
Related Parameter(s): P108, P109, P110, t201, t202,
A401, A402
Values A410 Default
A411 Default
A412 Default
A413 Default
0.0 Hz
5.0 Hz
10.0 Hz
20.0 Hz
Min/Max: 0.0/400.0 Hz
Display: 0.1 Hz
Provides a fixed frequency command value when
t201 - t202 [Digital Inx Sel] is set to 4 “Preset
Frequencies”.
An active preset input will override speed c
ommand as shown in the flowchart on page 1-20.
(1)
To activate A410 [Preset Freq 0] set P108 [Speed Reference] to option 4 “Preset Freq 0-3”.
Input State of Digital In 1
(I/O Terminal 05)
Input State of Digital In 2
(I/O Terminal 06) Frequency Source Accel / Decel Parameter Used
(2)
00A410 [Preset Freq 0] [Accel Time 1] / [Decel Time 1]
10A411
[Preset Freq 1] [Accel Time 1] / [Decel Time 1]
01A412
[Preset Freq 2] [Accel Time 2] / [Decel Time 2]
11A413
[Preset Freq 3] [Accel Time 2] / [Decel Time 2]
(2)
When a Digital Input is set to “Accel 2 & Decel 2”, and the input is active, that input overrides the settings in
this table.
A418 [Skip Frequency] Related Parameter(s): A419
Sets the frequency at which the drive will not operate.
A setting of 0 disables this parameter.
Values Default 0 Hz
Min/Max: 0/400 Hz
Display: 1 Hz
