A-4 Supplemental Drive Information
PowerFlex 4M Adjustable Frequency Drive FRN 1.xx - 2.xx User Manual
Publication 22F-UM001D-EN-E
Category Specification
Environment Altitude: 1000 m (3300 ft) max. without derating
Maximum Surrounding Air
Temperature without derating:
IP20:
IP20 zero stacking:
–10 to 50° C (14 to 122° F)
–10 to 40° C (14 to 104° F)
Cooling Method
Convection:
Fan:
120V, 1-Phase, 0.75 kW (1 HP) and below
240V, 1-Phase, 0.4 kW (0.5 HP) and below
240V, 3-Phase, 0.75 kW (1 HP) and below
480V, 3-Phase, 0.75 kW (1 HP) and below
All other drive ratings.
Storage Temperature: –40 to 85 degrees C (–40 to 185 degrees F)
Atmosphere: Important: Dr
ive must not be installed in an
area where the ambient atmosphere contains
volatile or corrosive gas, vapors or dust. If the
drive is not going to be installed for a period of
time, it must be stored in an area where it will not
be exposed to a corrosive atmosphere.
Relative Humidity: 0 to 95% non-condensing
Shock (operating): 15G peak for 11ms duration (±1.0ms)
Vibration (operating): 1G peak, 5 to 2000 Hz
Control Carrier Frequency 2-10 kHz. Drive rating based on 4 kHz.
Frequency Accuracy
Digital Input:
Analog Input:
Within ±0.05% of set output frequency.
Within 0.5% of maximum output frequency.
Speed Regulation - Open Loop
with
Slip Compensation:
±2% of base speed across a 40:1 speed range.
Stop Modes: Multiple programmable stop modes including -
Ramp
, Coast, DC-Brake, Ramp-to-Hold and
S Curve.
Acceleration/Deceleration: Two independently programmable acceleration
and de
celeration times. Each time may be
programmed from 0 - 600 seconds in 0.1 second
increments.
Intermittent Overload: 150% Overload capability for up to 1 minute
200% Overload capability for up to 3 seconds
Electronic Motor Overload
P
rotection
Provides class 10 motor overload protection
according to NEC article 430 and motor
over-temperature protection according to NEC
article 430.126 (A) (2). UL 508C File 29572.
Electrical Voltage Tolerance:
200-240V ±10%
380-480V ±10%
460-600V ±10%
Frequency Tolerance:
48-63 Hz
Input Phases: Three-phase input provides full rating. Single-phase
ope
ration provides 35% rated current.
Displacement Power Factor: 0.98 across entire speed range
Maximum Short Circuit Rating: 100,000 Amps Symmetrical
Actual Short Circuit Rating: Determined by AIC Rating of installed fuse/circuit
break
er
Transistor Type: Isolated Gate Bipolar (IGBT)
