Allen-Bradley PowerFlex 4M User Manual

Supplemental Drive Information A-5
PowerFlex 4M Adjustable Frequency Drive FRN 1.xx - 2.xx User Manual
Publication 22F-UM001D-EN-E
PowerFlex 4M Estimated Watts Loss (Rated Load, Speed & PWM)
Voltage kW (HP) Watts Loss
100–120V, 1-Phase 0.2 (0.25)
0.4 (0.5)
0.75 (1.0)
1.1 (1.5)
17
28
50
76
200–240V, 1-Phase 0.2 (0.25)
0.4 (0.5)
0.75 (1.0)
1.5 (2.0)
2.2 (3.0)
14
25
43
82
109
200–240V, 3-Phase 0.2 (0.25)
0.4 (0.5)
0.75 (1.0)
1.5 (2.0)
2.2 (3.0)
3.7 (5.0)
5.5 (7.5)
7.5 (10)
16
26
44
84
115
159
239
329
380–480V, 3-Phase 0.4 (0.5)
0.75 (1.0)
1.5 (2.0)
2.2 (3.0)
3.7 (5.0)
5.5 (7.5)
7.5 (10)
11 (15)
24
41
74
92
135
190
294
378

Allen-Bradley PowerFlex 4M Specifications

General

Input Voltage	200…240V AC, 380…480V AC, 500…600V AC
Output Voltage	0-Input Voltage
Control Method	Sensorless Vector
Communications	RS-485
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Enclosure	IP20
Operating Temperature	-10°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	5-95% (non-condensing)
Dimensions	Varies by model
Weight	Varies by model
