Accessories and Dimensions B-11
PowerFlex 4M Adjustable Frequency Drive FRN 1.xx - 2.xx User Manual
Publication 22F-UM001D-EN-E
Figure B.7 Frame C EMC Line Filters – Dimensions are in millimeters and (inches)
Catalog Number: 22F-RF039-CS, 22F-RF039-CL; 22F-RF026-CS, 22F-RF026-CL
32.0
(1.26)
60.0
(2.36)
309.0
(12.17)
90.0
(3.54)
130.0
(5.12)
30.0
(1.18)
297.0
(11.69)
297.0
(11.69)
309.0
(12.17)
17.0
(0.67)
5.5 (0.22)
5.5 (0.22)
