Rockwell Automation Publication 520-UM001A-EN-E - February 2013 75
Programming and Parameters Chapter 3
Options 47 Reserved
48 “2-Wire FWD”
(only for DigIn TermBlk 02)
[DigIn TermBlk 02] default. Selects 2-Wire FWD for this input.
Select this option and set P046
, P048 or P050 [Start Source x] to 2 “DigIn TrmBlk” to configure [Start Source x] to a 2-wire run
forward mode. Also see t064 [2-Wire Mode] for level trigger settings.
49 “3-Wire Start”
(only for DigIn TermBlk 02)
Select 3-Wire Start for this input.
Select this option and set P046, P048 or P050 [Start Source x] to 2 “DigIn TrmBlk” to configure [Start Source x] to a 3-wire start
mode.
50 “2-Wire REV”
(only for DigIn TermBlk 03)
[DigIn TermBlk 03] default. Selects 2-Wire REV for this input.
Select this option and set P046, P048 or P050 [Start Source x] to 2 “DigIn TrmBlk” to configure [Start Source x] to a 2-wire run
reverse mode. Also see t064 [2-Wire Mode] for level trigger settings.
51 “3-Wire Dir”
(only for DigIn TermBlk 03)
Select 3-Wire Dir for this input.
Select this option and set P046, P048 or P050 [Start Source x] to 2 “DigIn TrmBlk” to change the direction of [Start Source x].
52 “Pulse Train”
(only for DigIn TermBlk 07)
Selects pulse train for this input.
Use P047
, P049 and P051 [Speed Referencex] to select pulse input. Jumper for DigIn TermBlk 07 Sel must be moved to Pulse In.
(1) This function may be tied to one input only.
t064 [2-Wire Mode] Related Parameter(s): P045, P046, P048, P050, t062, t063
Stop drive before changing this parameter.
Programs the mode of trigger only for t062 [DigIn TermBlk 02] and t063 [DigIn TermBlk 03] when 2-wire option is being selected as P046, P048 or P050 [Start Source x].
Options 0 “Edge Trigger” (Default) Standard 2-Wire operation.
1 “Level Sense I/O Terminal 01 “Stop” = Coast to stop. Drive will restart after a Stop command when:
Stop is removed
and
Start is held active
I/O Terminal 03 “Run REV”
2 “Hi-Spd Edge”
Outputs are kept in a ready-to-run state. The drive will respond to a Start command within 10 ms.
I/O Terminal 01 “Stop” = Coast to stop.
I/O Terminal 03 “Run REV”
3“Momentary Drive will start after a momentary input from either the Run FWD input (I/O Terminal 02) or the Run REV input (I/O Terminal
03).
I/O Terminal 01 “Stop” = Stop according to the value set in P045 [Stop Mode].
ATTENTION: Hazard of injury exists due to unintended operation. When set to option 3, and the Run input
is maintained, the Run inputs do not need to be toggled after a Stop input for the drive to run again. A Stop
function is provided only when the Stop input is active (open).
There is greater potential voltage on the output terminals when using this option.
