Allen-Bradley PowerFlex 700H Service Manual

B-2 Schematics
Power Wiring Diagrams
Phase U Power Circuitry for Drives with AC Input
Figure B.1 Phase U Power Circuitry for Drives with AC In
p
ut
55
5
U/T1
I3
TERM 3
I2
I1
TERM 2
TERM 1
Power Board
U_HI
U_LO
V_HI
V_LO
W_HI
W_LO
Driver Board
X1
To Voltage Feedback J1
X6 X7 X8
X10 X11 X12
X6 H15 H16
Fiber Optic Cables
From ASIC Board X3
From ASIC Board H8
From ASIC Board H9
10
To 80W Power Supply J2
To ASIC Board X6
DC+
DC-
From Phase V
See Note 1
Note 1 - 400V/600V Capacitor Configuration 400V - 3 Caps in Series, 2 Caps in Parallel 600V - 2 Caps in Series, 3 Caps in Parallel
