2-10 Component Test Procedures
9. Connect the High Voltage DC Test Power Supply DC+ to the DC+ on
each Gate Driver board.
10. Set the current limit on the High Voltage DC Test Power Supply to less
than or equal to 1A. Energize the Supply and increase its output to the
drive’s nominal DC bus voltage (650V dc for drives with 380-500V ac
input or 775V dc for drives with 600-690V ac input).
Checking the Opto-Couplers
Class 1 LED Product
!
ATTENTION: The sheet metal cover and mounting screws on
the ASIC board located on the power structure are energized at
(-) DC bus potential high voltage. Risk of electrical shock,
injury, or death exists if someone comes into contact with the
assembly. Servicing energized equipment can be hazardous.
Severe injury or death can result from electrical shock, burn or
unintended actuation of controlled equipment. Follow Safety
related practices of NFPA 70E, ELECTRICAL SAFETY FOR
EMPLOYEE WORKPLACES. DO NOT work alone on energized
equipment!
!
ATTENTION: Certain pins in connectors X7 and X12 on the
Gate Driver board will be energized at DC bus potential high
voltage. Risk of electrical shock,
personal injury or death, property
damage, or economic loss exists if
personnel or equipment comes
into contact with these pins.
!
ATTENTION: Hazard of permanent eye damage exists when
using optical transmission equipment. This product emits intense
light and invisible radiation. Do not look into module ports or
fiber-optic cable connectors.
