Allen-Bradley PowerFlex 750 Series Programming Manual

Rockwell Automation Publication 750-PM001N-EN-P - February 2017 111
Drive Port 0 Parameters Chapter 3
SPEED CONTROL
Speed Reference
559 Save MOP Ref
Save Motor Operated Potentiometer Reference
RW 16-bit
Integer
Enables/disables the feature that saves the present MOP Ref value at power down or stop.
560 MOP Rate
Motor Operated Potentiometer Rate
Sets the rate of change of the MOP reference when an increasing or decreasing MOP
signal is present.
Units:
Default:
Min/Max:
%/s
1.0000
0.0100 / 100.0000
RW Real
561 MOP High Limit
Motor Operated Potentiometer High Limit
Sets the upper limit for the MOP Reference.
Units:
Default:
Min/Max:
%
100.000
0.000 / 800.000
RW Real
562 MOP Low Limit
Motor Operated Potentiometer Low Limit
Sets the lower limit for the MOP Reference.
Units:
Default:
Min/Max:
%
–100.000
–800.000 / 0.000
RW Real
563 DI ManRef Sel
Digital Input Manual Reference Select
Selects a speed reference to be used when a digital input activates Manual control,
according to the operation described by P172 [DI Manual Ctrl].
Default:
Min/Max:
872
1 / 159999
RW 32-bit
Integer
564 DI ManRef AnlgHi
Digital Input Manual Reference Analog High
High scale for the manual speed reference that is activated by a digital input when P563
[DI ManRef Sel] is connected to an Analog Input.
Units:
Default:
Min/Max:
Hz
RPM
P520 [Max Fwd Speed]
P521 [Max Rev Speed] / P520 [Max Fwd
Speed]
RW Real
565 DI ManRef AnlgLo
Digital Input Manual Reference Analog Low
Used only when P563 [DI ManRef Sel] has selected an analog input as the source of the
speed reference. Specifies the speed reference value that will be associated with the
Analog In Lo parameter for the I/O Module. Example, P563 [DI ManRef Sel] has selected
P50 [Anlg In0 Value] on an I/O Module. The P51 [Anlg In0 Hi] parameter on the I/O
Module is set to -10 volts. P564 [DI ManRef AnlgHi] will specify the speed reference
value that will correspond with a -10 volt analog input signal.
Units:
Default:
Min/Max:
Hz
RPM
0.000
P521 [Max Rev Speed] / P520 [Max Fwd
Speed]
RW Real
566 MOP Init Select
Motor Operated Potentiometer Initialization Select
Defines the initial MOP value when the MOP is not configured to start at the “At Power
Down” or “At Stop” values selected in P559 [Save MOP Ref].
Default:
Min/Max:
567
0 / 159999
RW 32-bit
Integer
567 MOP Init Stpt
Motor Operated Potentiometer Initialization Setpoint
A configurable set point to be used with the MOP initialization function.
Units:
Default:
Min/Max:
%
0
–/+8.00
RW Real
571
572
573
574
575
576
577
Preset Speed 1
Preset Speed 2
Preset Speed 3
Preset Speed 4
Preset Speed 5
Preset Speed 6
Preset Speed 7
Preset Speed n
Discrete speed references that are activated by a digital input function (see Digin
Functions) or by Logic Command (sent over a communication network or DeviceLogix).
Units:
Default:
Min/Max:
Hz
RPM
Based on P27 [Motor NP Hertz]/P28 [Motor
NP RPM] and Voltage Class
P521 [Max Rev Speed] / P520 [Max Fwd
Speed]
RW Real
File Group
No. Display Name
Full Name
Description
Values
Read-Write Data Type
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved At Stop At Pwr Down
Default0000000000000000
Bit 1514131211109876543210
0 = False
1 = True
