Rockwell Automation Publication 750-PM001N-EN-P - February 2017 147
Drive Port 0 Parameters Chapter 3
File
Group
No. Display Name
Full Name
Description
Values
Read-Write
Data Type
COMMUNICATION
Security
885 Port Mask Act
Port Mask Active
RO 16-bit
Integer
Active status for port communication. Bit 15 “Security” determines if network security is controlling the port mask instead of this parameter. For example, bit 15
can be active (control the port mask) when Automatic Device Configuration (ADC) is active.
886 Logic Mask Act
Logic Mask Active
RO 16-bit
Integer
Active status of the logic mask for ports. Bit 15 “Security” determines if network security is controlling the logic mask instead of this parameter.
887 Write Mask Act
Write Mask Active
RO 16-bit
Integer
Active status of write access for ports. Bit 15 “Security” determines if network security is controlling the write mask instead of this parameter.
888 Write Mask Cfg
Write Mask Configuration
RW 16-bit
Integer
Enables/disables write access (parameters, links, etc.) for DPI ports. Changes to this parameter only become effective when power is cycled, the drive is reset or bit
15 of P887 [Write Mask Act], transitions from “1” to “0.”
Options
Security
Port 14
Port 13
Reserved
Port 11
Port 10
Port 9
Port 8
Port 7
Port 6
Port 5
Port 4
Port 3
Port 2
Port 1
Digital In
Default0000000000000000
Bit 1514131211109876543210
0 = Read Only
1 = Read/Write
Options
Security
Port 14
Port 13
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Port 6
Port 5
Port 4
Port 3
Port 2
Port 1
Digital In
Default0000000000000000
Bit 1514131211109876543210
0 = Read Only
1 = Read/Write
Options
Security
Port 14
Port 13
Reserved
Port 11
Port 10
Port 9
Port 8
Port 7
Port 6
Port 5
Port 4
Port 3
Port 2
Port 1
Reserved
Default0000000001111110
Bit 1514131211109876543210
0 = Read Only
1 = Read/Write
Options
Reserved
Port 14
Port 13
Reserved
Port 11
Port 10
Port 9
Port 8
Port 7
Port 6
Port 5
Port 4
Port 3
Port 2
Port 1
Reserved
Default0110111111111110
Bit 1514131211109876543210
0 = Read Only
1 = Read/Write
