Allen-Bradley PowerFlex 750 Series Programming Manual

226 Rockwell Automation Publication 750-PM001N-EN-P - February 2017
Chapter 4 Port 10 and Port 11 Parameters
PRECHARGE N
Status
105
205
305
P1 Fault Status1
P2 Fault Status1
P3 Fault Status1
Precharge n Fault Status 1
RO 32-bit
Integer
Indicates which fault conditions currently exist for precharge n. Refer to Chapter
6 - Converter (Port 11) Faults and Alarms (Frame 8 and Larger) for information on
these fault codes.
106
206
306
P1 Fault Status2
P2 Fault Status2
P3 Fault Status2
Precharge n Fault Status 2
RO 32-bit
Integer
Indicates which fault conditions currently exist for precharge n. Refer to Chapter
6 - Converter (Port 11) Faults and Alarms (Frame 8 and Larger) for information on
these fault codes.
107
207
307
P1 Alarm Status1
P2 Alarm Status1
P3 Alarm Status1
Precharge n Alarm Status 1
RO 32-bit
Integer
Indicates which alarm conditions currently exist for precharge n. Refer to Chapter
6 - Converter (Port 11) Faults and Alarms (Frame 8 and Larger) for information on
these alarm codes.
File Group
No. Display Name
Full Name
Description
Values
Read-Write Data Type
755 (8+)
755 (8+)
755 (8+)
Options
MCSAuxCntact MCSCloseFail MCSShuntTrip Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved BusUnderVolt DiscnnectErr 240V AC Loss Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Precharge
Default00000000000000000000000000000000
Bit 313029282726252423222120191817161514131211109 8 7 6 5 4 3 2 1 0
0 = False
1 = True
755 (8+)
755 (8+)
755 (8+)
Options
Reserved Fault Q Full Reserved Reserved Reserved BusNgFuseFlt BusPsFuseFlt BusFuseHrnss Bus Shorted Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Firmware Flt Comm Loss Pwr Supp Flt Brd NTCShort Brd NTC Open Brd OvrTemp Reserved Reserved Reserved Reserved MCS Closed
Default00000000000000000000000000000000
Bit 313029282726252423222120191817161514131211109 8 7 6 5 4 3 2 1 0
0 = False
1 = True
755 (8+)
755 (8+)
755 (8+)
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Door Open Bus Overvolt BusUnderVolt DiscnnctOpen 240V AC Loss Reserved Reserved Reserved Bus Dip Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Precharge
Default00000000000000000000000000000000
Bit 313029282726252423222120191817161514131211109 8 7 6 5 4 3 2 1 0
0 = False
1 = True
