Rockwell Automation Publication 750-PM001N-EN-P - February 2017 41
Parameter Organization Chapter 2
Embedded DeviceLogix (Port 14)
Embedded DeviceLogix parameters are only used by PowerFlex 755 drives.
Parameter descriptions begin on page 239
.
File Group Parameters
Embedded
DeviceLogix Host
Groups
Analog Outputs DLX Out 01 1
DLX Out 02 2
DLX Out 03 3
DLX Out 04 4
DLX Out 05 5
DLX Out 06 6
DLX Out 07 7
DLX Out 08 8
DLX Out 09 9
DLX Out 10 10
DLX Out 11 11
DLX Out 12 12
DLX Out 13 13
DLX Out 14 14
DLX Out 15 15
DLX Out 16 16
Analog Inputs DLX In 01 17
DLX In 02 18
DLX In 03 19
DLX In 04 20
DLX In 05 21
DLX In 06 22
DLX In 07 23
DLX In 08 24
DLX In 09 25
DLX In 10 26
DLX In 11 27
DLX In 12 28
DLX In 13 29
DLX In 14 30
DLX In 15 31
DLX In 16 32
Digital Inputs DLX DIP 01 33
DLX DIP 02 34
DLX DIP 03 35
DLX DIP 04 36
DLX DIP 05 37
DLX DIP 06 38
DLX DIP 07 39
DLX DIP 08 40
DLX DIP 09 41
DLX DIP 10 42
DLX DIP 11 43
DLX DIP 12 44
DLX DIP 13 45
DLX DIP 14 46
DLX DIP 15 47
DLX DIP 16 48
Status & Cntl DLX DigIn Sts 49 DLX DigOut Sts 50
DLX DigOut Sts2 51
DLX Prog Cond 52 DLX Operation 53
Internal Regs DLX Real SP1 54
DLX Real SP2 55
DLX Real SP3 56
DLX Real SP4 57
DLX Real SP5 58
DLX Real SP6 59
DLX Real SP7 60
DLX Real SP8 61
DLX Real SP9 62
DLX Real SP10 63
DLX Real SP11 64
DLX Real SP12 65
DLX Real SP13 66
DLX Real SP14 67
DLX Real SP15 68
DLX Real SP16 69
DLX DINT SP1 70
DLX DINT SP2 71
DLX DINT SP3 72
DLX DINT SP4 73
DLX DINT SP5 74
DLX DINT SP6 75
DLX DINT SP7 76
DLX DINT SP8 77
DLX Bool SP1 78
DLX Bool SP2 79
DLX Bool SP3 80
DLX Bool SP4 81
DLX Real InSP1 82
DLX Real InSP2 83
DLX Real InSP3 84
DLX Real InSP4 85
DLX Real InSP5 86
DLX Real InSP6 87
DLX Real InSP7 88
DLX Real InSP8 89
DLX Real OutSP1 90
DLX Real OutSP2 91
DLX Real OutSP3 92
DLX Real OutSP4 93
DLX Real OutSP5 94
DLX Real OutSP6 95
DLX Real OutSP7 96
DLX Real OutSP8 97
DLX DINT InSP1 98
DLX DINT InSP2 99
DLX DINT InSP3 100
DLX DINT InSP4 101
DLX DINT OutSP1 102
DLX DINT OutSP2 103
DLX DINT OutSP3 104
DLX DINT OutSP4 105
Embedded DeviceLogix
