460 Rockwell Automation Publication 750-PM001N-EN-P - February 2017
Appendix C Application Notes
Gather Motor and Pump Data
Complete the table with the motor nameplate and pump data listed.
Enter Motor Data
Enter the motor data from above and adjust parameter settings.
Motor Data
Motor Nameplate Volts V
Motor Nameplate FLA A
Motor Nameplate Hertz Hz
Motor Nameplate RPM RPM
Motor Nameplate Power Hp
Motor Poles Pole
Pump Data
Gearbox Sheave Diameter in.
Gearbox Ratio :
Gearbox Rating kin#
Motor Sheave Diameter in.
Parameter Setting
Parameter Access Level
P301 [Access Level] 2 “Expert”
Motor Nameplate Data
P25 [Motor NP Volts] Motor nameplate voltage.
P26 [Motor NP Amps] Motor nameplate current.
P27 [Motor NP Hertz] Motor nameplate frequency.
P28 [Motor NP RPM] Motor nameplate speed.
P29 [Mtr NP Pwr Units] 0 “HP” or 1 “kW”
P30 [Motor NP Power] Motor nameplate power rating.
P31 [Motor Poles] Number of motor poles.
Motor Control
P35 [Motor Ctrl Mode] 3 “Induction FV”
