Drive Port 0 Parameters Chapter 3
FEEDBACK & I/O
Analog Inputs
264 Anlg In0 Raw Val
Analog Input 0 Raw Value
Raw Value of the analog input.
Units:
Default:
Min/Max:
Volt
mA
0.000 Volts
0.000 mA
–/+10.000 Volts
0.000 / 20.000 mA
RO Real
265 Anlg In0 Filt Gn
Analog Input 0 Filter Gain
Sets the analog input filter gain. The default setting represents no filtering.
Default:
Min/Max:
1.00
–/+5.00
RW Real
266 Anlg In0 Filt BW
Analog Input 0 Filter Bandwidth
Sets the analog input filter bandwidth. The default setting represents no filtering.
Default:
Min/Max:
0.0
0.0 / 500.0
RW Real
File Group
No. Display Name
Full Name
Description
Values
Read-Write Data Type
753
753
753
File Group
No. Display Name
Full Name
Description
Values
Read-Write Data Type
FEEDBACK & I/O
Analog Outputs
270 Anlg Out Type
Analog Output Type
RW 16-bit
Integer
Select the analog output mode for each analog output.
271 Anlg Out Abs
Analog Output Absolute
RW 16-bit
Integer
Selects whether the signed value or absolute value of a parameter is used before being scaled to drive the analog output.
275 Anlg Out0 Sel
Analog Output 0 Select
Selects the source for the analog output.
Default:
Min/Max:
3
0 / 159999
RW 32-bit
Integer
276 Anlg Out0 Stpt
Analog Output 0 Setpoint
A possible source for an analog output. Can be used to control an analog output from a
communication device using a DataLink. Not affected by analog output scaling.
Units:
Default:
Min/Max:
Volt
mA
0.000 Volts
0.000 mA
–10/20 Volts
0.000 / 20.000 mA
RW Real
277 Anlg Out0 Data
Analog Output 0 Data
Displays the value of the source selected by P275 [Anlg Out0 Sel].
Default:
Min/Max:
0
–/+100000
RO Real
278 Anlg Out0 DataHi
Analog Output 0 Data High
Sets the high value for the data range of analog out scale.
Units:
Default:
Min/Max:
pu
1.00
–/+214748000.00
RW Real
753
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Analog Out 0
Default0000000000000000
Bit 1514131211109876543210
0 = Voltage Mode
1 = Current Mode
753
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Analog Out 0
Default0000000000000000
Bit 1514131211109876543210
0 = Signed
1 = Absolute
753
753
753
753
