Chapter 3 Drive Port 0 Parameters
DRIVE CFG
Start Features
351 SleepWake RefSel
Sleep Wake Reference Select
Selects the source of the input controlling the Sleep-Wake function.
Default:
Min/Max:
0 (Disabled)
0 / 159999
RW 32-bit
Integer
352 Sleep Level
Sleep Level
Defines the analog input level that will stop the drive.
Units:
Default:
Min/Max:
Volt, P351 = 0 (Disabled)
Volt or mA, P351 = not 0 (Port
Device Jumper Setting)
5.00 Volt (P351 = 0)
5.00 Volt / 0.00 mA (Port n Device
Jumper Setting)
0.00 / 10.00 Volt
0.00 / 20.00 mA
RW Real
353 Sleep Time
Sleep Time
Defines the amount of time at or below 352 [Sleep Level] before a Stop is issued.
Units:
Default:
Min/Max:
Secs
0.00
0.00 / 64800
RW Real
354 Wake Level
Wake Level
Defines the analog input level that will start the drive.
Units:
Default:
Min/Max:
Volt, P351 = 0 (Disabled)
Volt or mA, P351 = not 0 (Port n Device
Jumper Setting)
6.00 Volt (P351 = 0)
6.00 Volt / 12.00 mA (Port n Device Jumper
Setting)
0.00 / 10.00 Volt
0.00 / 20.00 mA
RW Real
355 Wake Time
Wake Time
Defines the amount of time at or above 354 [Wake Level] before a Start is issued.
Units:
Default:
Min/Max:
Secs
0.00
0.00 / 64800
RW Real
356 FlyingStart Mode
Flying Start Mode
Enables/disables the function which reconnects to a spinning motor at actual RPM
when a start command is issued. Functional in all motor control modes.
“Enhanced” (1) – This advanced mode performs the reconnect function quickly.
“Sweep” (2) – This frequency sweep mode is used with output sine filters.
Default:
Options:
0 = “Disabled”
0 = “Disabled”
1 = “Enhanced”
2 = “Sweep”
(1)
(1) Frames 1…7 only
RW 32-bit
Integer
357 FS Gain
Flying Start Gain
P356 [FlyingStart Mode] = 1 “Enhanced”: Proportional term used in the current
regulator which controls the reconnect function.
P356 [FlyingStart Mode] = 2 “Sweep”: Time required for the speed detection signal to
remain at the programmed level (P360). Units of 50 μs.
Default:
Min/Max:
1200.0
0.0 / 10000.0
RW Real
358 FS Ki
Flying Start Intergal Gain
P356 [FlyingStart Mode] = 1 “Enhanced”: Integral term used in the current regulator
which controls the reconnect function.
P356 [FlyingStart Mode] = 2 “Sweep”: Integral term used in the voltage recovery to the
normal V/Hz level.
Default:
Min/Max:
60.0
0.0 / 1000.0
RW Real
359 FS Speed Reg Ki
Flying Start Speed Regulator Integral Gain
P356 [FlyingStart Mode] = 1 “Enhanced”: Integral term used in the speed regulator
which controls the reconnect function.
P356 [FlyingStart Mode] = 2 “Sweep”: Time to sweep frequency in one direction. Units
of 10 μs.
Default:
Min/Max:
100.0
0.0 / 10000.0
RW Real
360 FS Speed Reg Kp
Flying Start Speed Regulator Proportional Gain
P356 [FlyingStart Mode] = 1 “Enhanced”: Proportional term used in the speed regulator
which controls the reconnect function.
P356 [FlyingStart Mode] = 2 “Sweep”: Programmed level for the speed detection signal.
The monitored signal needs to drop below this level to indicate motor speed.
Default:
Min/Max:
75.0
0.0 / 100000.0
RW Real
File
Group
No. Display Name
Full Name
Description
Values
Read-Write
Data Type
To Next Page
