Interpret the Attribute Tables
Chapter 3
Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018 125
ID Access
Rule
Attribute B E F P V T Conditional Implementation
2454 Set Feedback 2 Accel Filter Taps
N - N N N
2455 Set Feedback 2 Battery Absolute
N - N N N TM
1471 Set Feedback 2 Data Code
N - N N N TP,SS
1470 Set Feedback 2 Data Length
N - N N N TP,SS
2450 Set Feedback 2 Loss Action
N - N N N O-Enum
1 = Switch to Sensorless Fdbk (N) 2 = Switch to Redundant
Fdbk (N)
1464 Set Feedback 2 Polarity
N - N N N
1475 Set Feedback 2 Resolver Cable Balance
N - N N N RS
1474 Set Feedback 2 Resolver Excitation Frequency
N - N N N RS
1473 Set Feedback 2 Resolver Excitation Voltage
N - N N N RS
1472 Set Feedback 2 Resolver Transformer Ratio
N - N N N RS
1451 Get Feedback 2 Serial Number
N - N N N
1465 Set Feedback 2 Startup Method
R - R R R O-Enum
1 = Absolute (N)
1484 Set Feedback 2 Velocity Filter Bandwidth
N - N N N
2453 Set Feedback 2 Velocity Filter Taps
N - N N N
250 Set Feedback Commutation Aligned
- - Y Y Y O-Enum
2 = Motor Offset (Y) 3 = Self-Sense (N)
4 = Database Offset (N) Vxx
31 Set* Feedback Configuration R R R R R R O-Enum
0 = No Feedback (V/Y)(T/N)
3 = Load Feedback (P/N)(V/N)(T/N) 4 = Dual Feedback (P/N)
8 = Dual Integrator Feedback (P/N)
708 Set Feedback Data Loss User Limit
Y Y Y Y Y
706 Set Feedback Noise User Limit
N N N N N
707 Set Feedback Signal Loss User Limit
N N N N N
44 Set Feedback Unit Ratio
- - N N -
871 Set Flux Braking Enable
- N N N N Ind Motor only
528 Get Flux Current Error
- - Y Y Y
530 Get Flux Current Feedback
- - Y Y Y
525 Get Flux Current Reference
- - Y Y Y
557 Set Flux Integral Time Constant
- - N N N
556 Set Flux Loop Bandwidth
- - N N N
558 Set Flux Up Control
- Y Y Y Y Ind Motor only O-Enum
1 = Manual Delay (Y)
2 = Automatic Delay (Y)
559 Set Flux Up Time
- Y Y Y Y Ind Motor only
380 Set Flying Start Enable
- N - N -
381 Set Flying Start Method
- N - N - 0-Enum: V29
1 = Counter EMF (N)
2 = Sweep Frequency (N)
