Allen-Bradley PowerFlex 755 Reference Manual

Interpret the Attribute Tables
Chapter 3
Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018 179
ID Access
Rule
Attribute B E F P V T Conditional Implementation
1326 Set Motor Winding to Ambient Resistance - N N N N
521 Get Operative Current Limit - - N N N
600 Get Output Frequency - R Y Y Y
508 Set Overtorque Limit - Y Y Y Y
509 Set Overtorque Limit Time - Y Y Y Y
2310 Set PM Motor Flux Saturation - N N N N PM Motor only
1343 Set PM Motor Force Constant - N N N N Rotary PM Motor only
1342 Set PM Motor Rated Force - N N N N Rotary PM Motor only
1339 Set PM Motor Rated Torque - N N N N Rotary PM Motor only
1340 Set PM Motor Torque Constant - N N N N Rotary PM Motor only
445 Set Position Error Tolerance Time - - Y - -
365 Get Position Fine Command - - Y - -
446 Set Position Integrator Control - - R - - O-Bits
1: Auto-Preset (N)
447 Set Position Integrator Preload - - N - -
781 Set Position Lead Lag Filter Bandwidth - - Y - -
782 Set Position Lead Lag Filter Gain - - Y - -
783 Set Position Notch Filter Frequency - - Y - -
627 Set Power Loss Action - Y Y Y Y O-Enum
2 = Decel Regen (Y)
628 Set Power Loss Threshold - Y Y Y Y
630 Set Power Loss Time - Y Y Y Y
590 Set Proving Configuration - - Y Y Y Y V28
376 Set* Ramp Acceleration - Y - Y - Derived
377 Set* Ramp Deceleration - Y - Y - Derived
378 Set Ramp Jerk Control - Y - Y -
375 Set* Ramp Velocity - Negative - Y - Y - Derived
374 Set* Ramp Velocity - Positive - Y - Y - Derived
613/354 Set Resistive Brake Contact Delay - N N N N PM Motor only
1333 Set Rotary Motor Damping Coefficient - N N N N Rotary Motor only
2312 Set Rotary Motor Fan Cooling Derating - N N N N Rotary Motor only
2311 Set Rotary Motor Fan Cooling Speed - N N N N Rotary Motor only
1330 Set Rotary Motor Inertia - N Y Y N Rotary Motor only
1332 Set Rotary Motor Max Speed - N N N N Rotary Motor only
629 Set Shutdown Action - N N N N O-Enum
1 = Drop DC Bus (N)
370 Set Skip Speed 1 - Y - - -
371 Set Skip Speed 2 - Y - - -
372 Set Skip Speed 3 - Y - - -
373 Set Skip Speed Band - Y - - -
833 Set SLAT Configuration - - - Y -

Allen-Bradley PowerFlex 755 Specifications

General

Category	AC Drive
Amperage	2.2…1470 A
Output Voltage	0 to Input Voltage
Output Current	2.2…1470 A
Enclosure	IP20, IP30, IP54
Communications	EtherNet/IP, ControlNet, DeviceNet
I/O	Digital, Analog, Encoder, Relay
Safety	Safe Speed Monitor
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overload, Short Circuit, Ground Fault, Overtemperature
Operating Temperature	-10°C to 50°C (14°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5…95% noncondensing
Altitude	Up to 1000m (3300ft) without derating
Voltage	200-240V AC, 380-480V AC, 500-600V AC, 690V AC
Input Voltage	200-240V AC, 380-480V AC, 500-600V AC, 690V AC
Control Method	Sensorless Vector
