Allen-Bradley PowerFlex 755 Reference Manual

Chapter 5
Module Configuration Attributes
484 Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018
The purpose of Demo Mode is to allow demonstration of products in
non-industrial environments. It is not intended for use in real motion
applications.
Converter Overtemperature User Limit
Usage Access T Data Type Default Min Max Semantics of Values
Optional - BD Set REAL 0 0
Degrees Celsius (°C)
This attribute sets the user limit for the Converter Overtemperature UL
exception.
Converter Thermal Overload User Limit
Usage Access T Data Type Default Min Max Semantics of Values
Optional - BD Set REAL 100 0
% Converter Rated
This attribute sets the user limit for the Converter Thermal Overload UL
exception.
Converter Ground Current User Limit
Usage Access T Data Type Default Min Max Semantics of Values
Optional - BD Set REAL 100 0
% Factory Limit
This attribute sets the user limit for the Converter Ground Current UL
exception.
Bus Regulator Overtemperature User Limit
Usage Access T Data Type Default Min Max Semantics of Values
Optional - BD Set REAL 0 0
Degrees Celsius (°C)
This attribute sets the user limit for the Bus Regulator Overtemperature UL
exception.

Allen-Bradley PowerFlex 755 Specifications

General

Category	AC Drive
Amperage	2.2…1470 A
Output Voltage	0 to Input Voltage
Output Current	2.2…1470 A
Enclosure	IP20, IP30, IP54
Communications	EtherNet/IP, ControlNet, DeviceNet
I/O	Digital, Analog, Encoder, Relay
Safety	Safe Speed Monitor
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overload, Short Circuit, Ground Fault, Overtemperature
Operating Temperature	-10°C to 50°C (14°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5…95% noncondensing
Altitude	Up to 1000m (3300ft) without derating
Voltage	200-240V AC, 380-480V AC, 500-600V AC, 690V AC
Input Voltage	200-240V AC, 380-480V AC, 500-600V AC, 690V AC
Control Method	Sensorless Vector
