Allen-Bradley PowerFlex 755 Reference Manual

Chapter 5
Module Configuration Attributes
486 Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018
This attribute sets the user limit for the Converter Pre-Charge Overload UL
exception.
Digital Output Configuration
Usage Access T Data Type Default Min Max Semantics of Values
Optional - All Set REAL []=0 - - Enumeration:
0 = Unassigned
1 = Contactor Enable
2 = Mechanical Brake
3 = Resistive Brake
4-255 = (reserved)
[ Axis 1 Output Config[8],
Axis 2 Output Config[8],
Axis 3 Output Config[8],
Axis 4 Output Config[8],
Axis 5 Output Config[8],
Axis 6 Output Config[8],
Axis 7 Output Config[8],
Axis 8 Output Config[8]]
This attribute is a 2 dimensional array of enumerated values that map configurable
digital output to specific functions for each drive axis. Each of the 8 possible axis
instances may support up to 8 configurable digital outputs. The Logix controller
distributes the Digital Output Configuration array elements to each axis instance
of the device. The Digital Output Configuration attribute in the device is defined
as a 32 element array of which only the first 8 elements are supported by this 8x8
Digital Output Configuration array definition. The remaining elements of the 32
element array are set to 0.

Allen-Bradley PowerFlex 755 Specifications

General

Category	AC Drive
Amperage	2.2…1470 A
Output Voltage	0 to Input Voltage
Output Current	2.2…1470 A
Enclosure	IP20, IP30, IP54
Communications	EtherNet/IP, ControlNet, DeviceNet
I/O	Digital, Analog, Encoder, Relay
Safety	Safe Speed Monitor
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overload, Short Circuit, Ground Fault, Overtemperature
Operating Temperature	-10°C to 50°C (14°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5…95% noncondensing
Altitude	Up to 1000m (3300ft) without derating
Voltage	200-240V AC, 380-480V AC, 500-600V AC, 690V AC
Input Voltage	200-240V AC, 380-480V AC, 500-600V AC, 690V AC
Control Method	Sensorless Vector
