Introduction to Control Builder Components 1-5
Functional relation category
Control Builder includes comprehensive libraries of function blocks
that streamline the control strategy configuration process. You simply
“drag and drop” selected blocks into a Control Module and/or
Sequential Control Module container to emulate the necessary
functional requirements of your process.
See the Control Builder Reference Manual, publication 1757-RM808,
for more information.
The functional relation category conveniently groups function blocks
according to a related functional block type or component library. The
component libraries provide a convenient way to group related
function blocks for easy access and reference.
Figure 1.3 on page 1-5 shows the general graphic orientation and
Windows look-and-feel of Control Builder.
Figure 1.3 TypicalView of control module configuration in Control Builder.
