Alliance Laundry Systems SWT520*M - Washer Is Locked Up Or Binding

30 39201
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
General Troubleshooting
14. Washer Is Locked Up Or Binding
Washer is locked up or binding.
Is there
excessive
belt tension?
Replace belt
and/or idler
spring.
Yes
Is there a bind
in upper or
lower bearing?
Replace bearing.
Yes
Is there a
bind in water
pump?
No
Replace pump.
Yes
Is voltage
incorrect?
Contact local
utility company
or have a
qualified
electrician
check power
supply.
TLW338S
No
Are brake
pads
binding?
Free binding
pads or
replace pads.
Yes
Repair or replace
transmission.
Yes
Is there a
bind in
transmission?
Yes
No
No
No
