Is
machine level?
(Machines that aren't
level may prevent coins from
following through required
check stages
of drop.)
No
Yes
No
Refer to wiring
diagram for
proper connections.
Yes
No
Yes
SWD1714S
Is proper
electrical power
supplied to coin drop?
(Incorrect electrical connection
may prevent coins from
registering in
coin drop.)
Is coin drop
clean? (Residue or
lint build-up may prevent
coins from following through
required check stages
of drop.)
Refer to
Adjustments section
for instructions on cleaning
drop.
Replace
coin drop sensor.
Refer to
Installation Instructions
for instructions
on leveling machine.
Do coins
fall freely
through drop?
No
Replace
coin drop.
Yes
To Next Page
