General Troubleshooting
18. Troubleshooting Coin Drop
a. Non-Electronic Coin Drops:
When coin is placed into coin slot, the coin should roll down drop and be heard dropping into coin vault. If coin
does not fall into coin vault or if coin drop sensor does not register that coin has been entered, follow
troubleshooting instructions on the following page. Refer to Figure 1 for path that coin follows when working
properly.
IMPORTANT: Never use oil to correct coin drop problems. Oil residue will prevent coins from rolling
properly.
IMPORTANT: Do not bend or damage mechanical parts within coin drop.
Figure 1
Additional coins following
path to sensor
Coin Drop
Sensor
Coin in
Coin Slot
To Next Page
