Alliance Laundry Systems SWT520*M - Coin Slide Does Not Return Freely

39201 43
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Troubleshooting (Coin Slide Operated/Non-Metered Models with “8” or “9” in 4th Character of Model No.)
23. Coin Slide Does Not Return Freely
Coin slide doesn't freely return.
Was the
wrong
extension
lever setup
used?
Are coin slide
switch and
extension
assemblies
equipped with
updated parts?
Replace with
assemblies that
have
nitrocarburized
(black-coated)
brackets and
lighter spring with
open hooks.
No
TLW376S
Consult coin slide
manufacturer
instructions, clean and
lubricate coin slide,
double check that return
springs are present.
Make sure one
or two stars,
depending on
type of coin
slide, face
down. Refer to
Installation
manual.
Yes
Review
extension lever
for proper free
rotation.
Is there a
burr present
on extension
lever or
switch
bracket?
Remove burr,
lubricate and
retest.
Yes
Yes
No
