General Troubleshooting
17. Water Leaking From Outer Tub
Water leaking from
outer tub.
Is water seal
in outer tub
leaking?
Replace hub
and seal kit
assembly.
Yes
Is there a
hole in outer
tub?
Replace outer
tub.
Yes
Is pressure
hose or
accumulator
leaking?
No
Replace
pressure hose
and/or
accumulator.
Yes
Is tub-to-
pump hose
leaking at
clamp?
Tighten clamp.
TLW341S
No
Is there an
obstruction in
drain causing
water to come
over top of outer
tub cover?
Remove
obstruction.
Yes
Replace gasket.
Yes
Is outer tub
cover
gasket
leaking?
Yes
No
No
No
