NOTE: The safety switch is an important component
which must, if correctly adjusted, stop the machine
when excessive movement and shaking occur due
to an unbalance caused by improper distribution of
linen in the washing drum or when the amount of
laundry exceeds the machine capacity.
Adjust the safety switch lever distance as follows, refer to
Figur
e 50 : The safety switch lever must be in the center of
the eye (left and right). Adjust the distance between the lower
edge of the eye and the safety switch lever, using two screws
on the safety switch holder. Refer to Table 39 . The function
of the vibration switch can be checked in the Inputs menu.
Specifica-
tion Model
Require-
ment, in.
[mm]
A - distance be-
tween lower edge
of lug and stick
of safety switch
6.5 kg - 13.5
kg /
14 lb. - 30 lb. /
65 L - 135 L
0.20 ± 0.04 [5
± 1]
18 kg - 28 kg /
40 lb. - 70 lb. /
180 L - 280 L
0.04 ± 0.04 [1
± 1]
Table 39
7. Check the door pressure and inspect the door seal. Replace it
as needed. Refer to instructions 4-18-215 for door pressure
adjustment and door seal replacement details.
8. After a cycle has been completed, check the shock absorbers
to see if they are warm. If the shock absorbers aren’
t warm
just after a wash cycle has been completed, replace them.
Maintenance
©
Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
76 Part No. D2418ENR6
