ALLIANCE 030 Series User Manual

© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
Installation
37
70458301ENR6
CE Orifices
Gas
Type
Gas
Family
Gas
Group
Gas
Designa-
tion
Supply
Pressure
Manifold
Pressure
Capacity
Model
Orifice
Diameter
in.
Orifice
Diameter
mm
Orifice
Part No.
Quantity
in. wc
(mbar, kPa)
in. wc
(mbar, kPa)
Natural
Gas
Second
I
2H(E)
G20
8/10
(20/25,
2.0/2.5)
3.25
(8, 0.8)
25 0.1540 3.9 M401020 1
30 0.1570 4.0 M402996 1
T30 0.1570 4.0 M402996 2
35 0.1820 4.6 M411371 1
T45 0.1820 4.6 M411371 2
55 0.2040 5.2 M402993 1
I
2L
G25
10
(25, 2.5)
4.4
(11, 1.1)
25 0.1540 3.9 M401020 1
30 0.1570 4.0 M402996 1
T30 0.1570 4.0 M402996 2
35 0.1820 4.6 M411371 1
T45 0.1820 4.6 M411371 2
55 0.2040 5.2 M402993 1
I
2E+
G20
8
(20, 2.0)
Un-
regulated
25 0.1220 3.1 70070903 1
30 0.1299 3.3 44253801 1
T30 0.1299 3.3 44253801 2
35 0.1440 3.7 M400998 1
T45 0.1440 3.7 M400998 2
55 0.1695 4.3 M402988 1
LP Third
I
3B/P
G30
11.25/12
(28/30,
2.8/3.0)
Un-
regulated
25 0.0820 2.1 M401027 1
30 0.0866 2.2 70070906 1
T30 0.0866 2.2 70070906 2
35 0.0980 2.5 M406361 1
T45 0.0935 2.4 M403017 2
55 0.1200 3.0 M401017 1
G30
14.9/20
(37/50,
3.7/5.0)
12
(30, 3.0)
25 0.0820 2.1 M401027 1
30 0.0866 2.2 70070906 1
T30 0.0866 2.2 70070906 2
35 0.0980 2.5 M406361 1
T45 0.0935 2.4 M403017 2
55 0.1200 3.0 M401017 1
I
3+/3P
G30 /G31
11.25/14.9
(28/37,
2.8/3.7)
Un-
regulated
25 0.0820 2.1 M401027 1
30 0.0866 2.2 70070906 1
T30 0.0866 2.2 70070906 2
35 0.0980 2.5 M406361 1
T45 0.0935 2.4 M403017 2
55 0.1200 3.0 M401017 1
Table 1
