ALLIANCE 030 Series User Manual

© Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT
Operating Instructions
70458301ENR6
86
DX4 Coin Control
3B, 3V, 3W and 3X Control Suffixes
1. Open door and fill drum with clothes.
2. Close door.
3. Insert the coin(s) in the coin slot.
4. Press and release one of the cycle buttons to
select a cycle and start the tumble dryer. Refer to
Table 20.
To use a custom cycle, refer to the Programming
Manual.
NOTE: Drying times will be dependent on the
number of coins that are inserted in the coin slot.
IMPORTANT: To stop the tumble dryer at any
time during the cycle, OPEN DOOR. To restart the
tumble dryer, CLOSE door and press START
button.
5. When the cycle is complete, open door and
remove the laundry.
DX4 OPL Control
3O and R3 Control Suffixes
1. Open door and fill drum with clothes.
2. Press and release one of the cycle buttons to
select a cycle and start the tumble dryer. Refer to
Table 21.
To use a custom cycle, refer to the Programming
Manual.
Table 21
IMPORTANT: To stop the tumble dryer at any
time during the cycle, OPEN DOOR. To restart the
tumble dryer, CLOSE door and press START
button.
3. When the cycle is complete, open door and
remove the laundry.
TMB2266N
Figure 50
Temperature
Drying
Time
Cool Down
Time
Left
Button
104°F (40°C) Varies 2 min.
Middle
Button
140°F (60°C) Varies 2 min.
Right
Button
176°F (80°C) Varies 2 min.
Table 20
WARNING
To prevent the risk of fire, remove laundry
immediately in case of power failure.
W779
TMB2266N
Figure 51
Temperature
Drying
Time
Cool Down
Time
Left
Button
104°F (40°C) 30 min. 2 min.
Middle
Button
140°F (60°C) 30 min. 2 min.
Right
Button
176°F (80°C) 35 min. 2 min.
WARNING
To prevent the risk of fire, remove laundry
immediately in case of power failure.
W779
