Gas Requirements
70458301ENR6
52
High Altitude Burner Orifice Sizing
For proper operation at altitudes above 2,000 feet
(610 m), the gas burner orifice size must be reduced to
ensure complete combustion. Refer to Table 6.
For CE models, consult local gas supplier.
Model Gas
Altitude Burner Orifice New Rate
feet meters # inches mm Quantity Part No. (Btu/hr.)*
025
Series
Natural Gas 2,001-4,000 610-1,220 26 0.1470 3.7
1
M401000 58,880
4,001-6,000 1,221-1,830 27 0.1440 3.7 M400998 53,760
6,001-8,000 1,831-2,440 28 0.1405 3.6 M401014 48,640
8,001-10,000 2,441-3,050 29 0.1360 3.4 M400997 43,520
L.P. Gas 2,001-6,000 610-1,830 43 0.0890 2.3 M406184 58,880
6,001-8,000 1,831-2,440 44 0.0860 2.2 M401011 48,640
8,001-10,000 2,441-3,050 46 0.0810 2.1 M401003 43,520
030
Series
Natural Gas 2,001-4,000 610-1,220 22 0.1570 4.0
1
M402996 67,160
4,001-6,000 1,221-1,830 24 0.1520 3.9 M402980 61,320
6,001-8,000 1,831-2,440 26 0.1470 3.7 M401000 55,480
8,001-10,000 2,441-3,050 28 0.1405 3.6 M401014 49,640
L.P. Gas 2,001-6,000 610-1,830 42 0.0935 2.4 M403017 67,160
6,001-8,000 1,831-2,440 43 0.0890 2.3 M406184 55,480
8,001-10,000 2,441-3,050 44 0.0860 2.2 M401011 49,640
T30
Series
Natural Gas 2,001-4,000 610-1,220 22 0.1570 4.0
2
M402996 134,320
4,001-6,000 1,221-1,830 24 0.1520 3.9 M402980 122,640
6,001-8,000 1,831-2,440 26 0.1470 3.7 M401000 110,960
8,001-10,000 2441-3,050 28 0.1405 3.6 M401014 99,280
L.P. Gas 2,001-6,000 610-1,830 42 0.0935 2.4 M403017 134,320
6,001-8,000 1,831-2,440 43 0.0890 2.3 M406184 110,960
8,001-10,000 2,441-3,050 44 0.0860 2.2 M401011 99,280
035
Series
Natural Gas 2,001-4,000 610-1,220 17 0.1730 4.4
1
M411374 82,800
4,001-6,000 1,221-1,830 18 0.1695 4.3 M402988 75,600
6,001-8,000 1,831-2,440 20 0.1610 4.1 M401002 68,400
8,001-10,000 2,441-3,050 22 0.1570 4.0 M402996 61,200
L.P. Gas 2,001-4,000 610-1,220 38 0.1015 2.6 M411376 82,800
4001-6000 1,221-1,830 39 0.0995 2.5 M401007 75,600
6,001-8,000 1,831-2440 41 0.0960 2.4 M401015 68,400
8,001-10,000 2,441-3,050 42 0.0935 2.4 M403017 61,200
T45
Series
Natural Gas 2,001-4,000 610-1,220 15 0.1800 4.6
2
M411511 183,000
4,001-6,000 1,221-1,830 17 0.1730 4.4 M411374 168,400
6,001-8,000 1,831-2,440 18 0.1695 4.3 M402988 155,000
8,001-10,000 2,441-3,050 20 0.1610 4.1 M401002 142,600
L.P. Gas 2,001-4,000 610-1,220 36 0.1065 2.7 M402487 183,000
4,001-6,000 1,221-1,830 37 0.1040 2.6 M411375 168,400
6,001-8,000 1,831-2,440 38 0.1015 2.6 M411376 155,000
8,001-10,000 2,441-3,050 40 0.0980 2.5 M406361 142,600
*Btu/hr. derate of 4% per 1,000 feet (305 meters) of altitude.
Table 6 (continued)
