Installation
70458301ENR6
40
Figure 15
TMB2252N
1 Gas Shut-Off Valve (Shown in closed position)
(Not Supplied)
6 Part No. 70201901 025 Series Natural Gas L.P.
Orifice Plate (For use on 025 Series Natural
Gas Models L.P. only)
2 Gas Valve
3 Burner Orifice 7 Required Burner Manifold Pressure
4 Regulator Adjusting Housing and Gasket
(Regulated version shown)
8 Manometer
9 Connect Over Loosened Slotted Pressure Tap
Screw in Bottom of Gas Valve5 Gas Valve Bracket
10 Spud Holder
To Next Page
