Specifications and Dimensions
15
70457901ENR7
Gas Connection Locations
TMB2239N
A
B
Diameter A B
050/075 – 1/2 in. NPT 14.75 in.
(375 mm)
65.75 in.
(1670 mm )
F75 – 3/4 in. NPT
