Electrical Requirements
70457901ENR7
48
Electrical Specifications
NOTE: Wire sizes were obtained from the
Canadian Electrical Code for 75 C. wire and are
intended for use as a guideline only. Electrical
connections should be made by a qualified
electrical contractor in accordance with all
applicable local and national requirements.
NOTE: Electrical specifications below are subject
to change without notice. Always refer to product
serial plate for most current specifications of
product being installed.
NOTE: Use copper conductors only.
NOTE: Connect to individual branch circuit.
NOTE: 3 Phase Only – Each tumble dryer must be
connected to its own individual branch circuit
breaker, not fuses, to avoid the possibility of “single
phasing” and causing premature failure of the
motor(s).
050 Series Gas and Steam Models
7
Serial Plate Rating
Terminal Block
Connections
Required
Serial Plate Amps Recommended Circuit
Nonreversing Reversing
Breaker
Rating
Wire Size
AWG (mm
2
)
120V/60Hz/1ph
L1, Neutral and ground 9.3 N/A 15A – 1 pole 14 (2.5)
200-208V/60Hz/1ph
L1, Neutral and ground 5.1 N/A 10A – 1 pole 14 (2.5)
200-208-240V/60Hz/1ph
L1, L2 and ground 5.1 N/A 10A – 2 pole 14 (2.5)
230-240V/50Hz/1ph
L1, Neutral and ground 6.3 6.9 15A – 1 pole 14 (2.5)
200-208/240V/60Hz/3ph
L1, L2, L3 and ground 2.8 4.0 10A – 3 pole 14 (2.5)
200V/50Hz/3ph
L1, L2, L3 and ground 3.3 4.2 10A – 3 pole 14 (2.5)
230-240V/50Hz/3ph
L1, L2, L3 and ground 3.1 4.3 10A – 3 pole 14 (2.5)
380V/50 or 60Hz/3ph
L1, L2, L3 and ground 1.6 2.0 10A – 3 pole 14 (2.5)
400-415V/50Hz/3ph
L1, L2, L3 and ground 1.6 2.0 10A – 3 pole 14 (2.5)
440V/60Hz/3ph
L1, L2, L3 and ground 1.4 1.9 10A – 3 pole 14 (2.5)
460-480V/60Hz/3ph
L1, L2, L3 and ground 1.4 1.9 10A – 3 pole 14 (2.5)
N/A = Not Applicable
Table 7
