ALLIANCE CA050L - 075 Series Gas and Steam Models; F75 Gas Models Only

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Electrical Requirements
49
70457901ENR7
075 Series Gas and Steam Models
F75 Gas Models Only
Serial Plate Rating
Terminal Block
Connections
Required
Serial Plate Amps Recommended Circuit
Nonreversing Reversing
Breaker
Rating
Wire Size
AWG (mm
2
)
120V/60Hz/1ph
L1, Neutral and ground 13.8 N/A 20A – 1 pole 12 (4)
200-208V/60Hz/1ph
L1, Neutral and ground 7.6 N/A 15A – 1 pole 14 (2.5)
200-208-240V/60Hz/1ph
L1, L2 and ground 7.6 N/A 15A – 2 pole 14 (2.5)
230-240V/50Hz/1ph
L1, Neutral and ground 6.7 7.0 15A – 1 pole 14 (2.5)
200-208/240V/60Hz/3ph
L1, L2, L3 and ground 3.8 4.3 10A – 3 pole 14 (2.5)
200V/50Hz/3ph
L1, L2, L3 and ground 3.5 4.5 10A – 3 pole 14 (2.5)
230-240V/50Hz/3ph
L1, L2, L3 and ground 3.5 4.9 10A – 3 pole 14 (2.5)
380V/50 or 60Hz/3ph
L1, L2, L3 and ground 1.8 2.1 10A – 3 pole 14 (2.5)
400-415V/50Hz/3ph
L1, L2, L3 and ground 1.8 2.1 10A – 3 pole 14 (2.5)
440V/60Hz/3ph
L1, L2, L3 and ground 1.9 2.1 10A – 3 pole 14 (2.5)
460-480V/60Hz/3ph
L1, L2, L3 and ground 1.9 2.1 10A – 3 pole 14 (2.5)
N/A = Not Applicable
Table 8
Serial Plate Rating
Terminal Block
Connections
Required
Serial Plate Amps Recommended Circuit
Nonreversing Reversing
Breaker
Rating
Wire Size
AWG (mm
2
)
200-208/240V/60Hz/3ph
L1, L2, L3 and ground N/A 6.3 15A – 3 pole 14 (2.5)
460-480V/60Hz/3ph
L1, L2, L3 and ground N/A 3.1 10A – 3 pole 14 (2.5)
N/A = Not Applicable
Table 9
