If lockout condition persists, check that the manual
gas shut-off valve is in the ON position and that the
gas service is properly connected. If condition still
persists, remove tumble dryer from service.
8. Load the cylinder with a full load of clean rags
and run to remove oil or dirt from cylinder.
9. Check the airflow switch operation refer to
Adjustments section. The heating systems should
shut off when the lint panel is opened a
maximum of 1.5 inches (38 mm).
The airflow switch operation may be affected by
shipping tape still in place, lack of make-up air,
or an obstruction in the exhaust duct. These
should be checked and the required corrective
action taken before attempting to adjust the
airflow switch. To adjust the airflow switch, refer
to Adjustments section.
Models
Prepurge
Time
(seconds)
Trial for
Ignition
(seconds)
Reset
Lockout
Condition
By:
Models through 3/10/13
CE and
Australia
18 10 025, 030,
035, 055:
Press reset
button on rear
of machine
T30, T45:
Press lighted
reset button
in rear
contactor box
All others
1-3 10 Open loading
door
Models starting 3/11/13
CE
110
(attempts to
ignite 3
times)
For models
with EO, RE,
RU or UO
control
suffixes:
Press start on
control
keypad.
For models
with all other
control
suffixes:
Press and
hold reset
button on
junction box
until light
goes out.
Non-CE
and non-
Australian
110
(attempts to
ignite 3
times)
Open loading
door
Models starting 3/11/13
through 7/31/13
Australia
18 10 025, 030,
035, 055:
Press reset
button on rear
of machine
T30, T45:
Press lighted
reset button
in rear
contactor box
(Continued)
(Continued)
Models
Prepurge
Time
(seconds)
Trial for
Ignition
(seconds)
Reset
Lockout
Condition
By:
Models starting 8/1/13
Australia
23 23 For models
with EO, RE,
RU or UO
control
suffixes:
Press start on
control
keypad.
For models
with all other
control
suffixes:
Press and
hold reset
button on
junction box
until light
goes out.
Do not operate tumble dryer if airflow
switch is faulty. An explosive gas mixture
could collect in tumble dryer if airflow
switch does not operate properly.
W407R1
WARNING
