ALLIED ELECTRONICS NeXGen User Manual

NeXGen  Gilbarco/Bennett - Installation and Start Up Guide
Copyright  2018 by Allied Electronics, Inc.
October 18, 2018 Page
3-29
Type Y
(EMV in S-DES – Compatible mode)
Notes:
1. EMV returns different values for CANCEL and ENTER when in buffered mode. The keys in this table
reflect the "normal" returns. CRIND code is responsible for handling the special case when in buffered
Auxiliary
Keypad
1 2 3 Cancel French
4 5 6 Clear
7 8 9
Enter (ok)
Shift 0 Help
Type Z
(EPP in T-DES – Graphics – Advantage and Encore 300 models w/o Auxiliary keys)
Notes:
1. Encrypting Pin Pads (EPP's) differ from other in the values that they return.
2. Column 4 does NOT exist on the physical keypad. It is included in this diagram only as a place holder.
3. Pushing the HELP key twice, functions as the ADA key.
1 2 3 Yes
4 5 6 No
7 8 9 Cancel
Clear 0 Enter Help ADA
