Shielding Installation, Crank Arm
Item Part No. Qty Description Item Part No. Qty Description
906833 Shield Installation
1 909551 1 . Plate, Rear Shield
2 909552 1 . Plate, Fnt Shield
3 903911 1 . Plate, Fnt Shield
4 399741W 9 . Screw, Ser Flg
5 SMS0000177 2 . Screw, Ser Flg
6 R13802619 13 . Flat Washer
7 264150W 4 . Nut
8 223428 7 . Flat Washer
9 191534W 2 . Nut
10 SMS0000184 5 . Screw, Ser Flg
Rev B
3
2
1
108
108
108
10 8
46
4
6
4 6
4 6
4 6
5
89
4 6 6 7
8 10
Shield Installation; Crank Arm
Page 1 of 1
