Network Adapter Card Installation Guide
177
3. At the DOS prompt, do one of the following:
If you copied the program files onto diskette, type:
a:\diag
If you are using a driver installation diskette, type:
a:\diag\diag
If you are using the Installation CD, type:
x:\drivers\diag\diag
where x: is the drive letter for the CD drive.
If the system contains just one Allied Telesyn adapter card, the
AT-Diag main menu is displayed, as shown in Figure 108.
Figure 108. AT-Diag Main Menu
The card’s model number, MAC address, and speed and duplex mode
are displayed at the top of the window. Also included is the default port,
which applies only to dual port adapters and specifies the port where
the Managed Boot Agent (MBA) is active, and the status of the
BootPROM chip.
Diagnostic Tests
Communication Test
Hardware Information
Settings
Select Adapter
Technical Support
MAC Address Speed / Duplex Default Port DefaultROM
00:30:84 32:8A:50 100Mb / Full 100Mb Fiber Enabled
Esc - Exit
AT-2701FX Ethernet Adapter Diagnostics v3.0
Allied Telesyn, Inc.
To Next Page
