Allied Telesis AT-8000S Series Installation Guide

Product Description
Page 9
Features
The AT-8000S/16, AT-8000S/24, AT-8000S/24POE, AT-8000S/48 and AT-8000S/48POE features include the
following:
• Wirespeed switching traffic across all ports
• Auto MDI/MDIX enabled
• 802.1d, 1w, 1s priority tags supported
• Broadcast storm control
• IEEE 802.1Q tagged VLANs supported
• GARP/GVRP supported
• Port/MAC based VLANs supported
• 802.3ad link aggregation Static and Dynamic (LACP) supported
• IEEE 802.1P based QoS supported
• Ingress rate limiting
• Egress rate shaping (WRR)
• 802.1x port/MAC based authentication support
• RFC 2618 RADIUS Authentication
• SSL/ SSLv3
• RFC 1492 TACACS+
• Management ACL support
• Industry standard CLI
• Browser based management interface (HTTP)
• Telnet access supported
• SNMP v1, v2 and v3
• RFC1757 RMON support
• Port Mirroring support
• PVE
• Port Security
• DHCP support
• Static IP Multicast support
• IGMP Snooping
IEEE Standards
– IEEE 802.3 — 10Base-T
– IEEE 802.3u — 100Base-TX
– IEEE 802.3ab — 1000Base-TX Gigabit Ethernet
– IEEE 802.3z — Full Duplex
– IEEE 802.3u — Auto-Negotiation
– IEEE 802.3x — Flow Control, Symmetric and Asymmetric

Allied Telesis AT-8000S Series Specifications

General

Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Humidity	5% to 95% non-condensing
Switching Capacity	104 Gbps
Forwarding Rate	77.4 Mpps
VLANs	4, 094
Layer 3 Features	Static routing, RIP v1/v2
Management	Web-based
Operating Humidity	10% to 90% non-condensing
