Allied Telesis AT-9924T User Manual

14 x900 Series Switch and SwitchBlade
®
x908
C613-03092-00 REV J
SwitchBlade x908 Key features are:
■ Autonegotiating, multi-layer gigabit switch
■ Out-of-band 10/100/1000BASE-T Ethernet management port
■ Optional Secure Digital memory card
■ Supports dual, hot-swappable, load sharing PSUs
■ Dual, hot-swappable chassis fans
■ Two fixed stacking connectors on the rear of the chassis
■ RoHS compliant
■ Eight high-speed bays to support a combination of expansion modules:
• XEM-1XP, 1 x 10 GbE XFP port
• XEM-2XP, 2 x 10 GbE XFP port
• XEM-12S, 12 x SFP ports
• XEM-12T, 12 x RJ-45 ports
• XEM-STK, 2 stacking ports
SwitchBlade x908 front panel with 8 XEMs
FAULT STATUS
STACKING SYSTEM
PORT 1 PORT 2 PSU 1 PSU 2
FAULT
NEGOTIATING
LINK
PORT
STAT
MEMBER
MASTER
AT-SBx908 Enhanced L3+ Modular Switch
SD
RESET
ETH0
Switch Blade
x908
1 2
6 7
3 4
8
CONSOLE
XEM-12T
XEM-12T
XEM-12T
XEM-12S
XFP
XFP
L/A
L/A
LINK ACT ENABLED DISABLED
FAULT
XEM-1XP
XFP
XFP
L/A
L/A
LINK ACT ENABLED DISABLED
FAULT
XEM-1XP
PORT 2PORT 1 STACK
SELECT STATUS
ID
XEM-STK
FAULTNEGOTIATING LINK
PORT
STAT
MEMBER MASTER
