18 x900 Series Switch and SwitchBlade
®
x908
C613-03092-00 REV J
Stacking LEDs The following LEDs report stacking operations and faults on the
SwitchBlade
x908 switch and the XEM-STK expansion module.
SD Green
flashing
The Secure Digital memory card is active and should not be ejected.
The card can be safely ejected when the LED remains off. Valid for
the AT-9924Ts, x900-12XT/S, x900-24XT, x900-24XT-N,
x900-24XS, and SwitchBlade x908 switches.
LED State Description (cont)
LED State Description
Port 1
and
Port 2
Green A link has been established.
Amber slow flashing The link has a transmission fault.
Status
Green The switch is the stack master.
Amber The switch is a stack member.
Green flashing The switch is in the process of learning the
stack topology and selecting the stack master.
Off The switch is not a stack member.
numeric ID
(XEM-STK only)
1 to 8 Numeric ID of the stack member.
Off The switch is not a stack member.
