AT-GS908M, AT-GS916M, and AT-GS924M Switches Installation Guide
43
Installing SFP Transceivers
To install an SFP transceiver, perform the following procedure:
The transceiver can be hot-swapped; you do not need to power off
the switch to install a transceiver. However, you should always
remove the cables before removing the transceiver.
You should always install the transceiver before connecting the
fiber-optic cables to it.
1. Remove the transceiver from its shipping container and store the
packaging material in a safe location.
An SFP transceiver can be damaged by static electricity. Be sure to
observe all standard electrostatic discharge (ESD) precautions,
such as wearing an antistatic wrist strap, to avoid damaging the
transceiver.
2. Remove the dust plug from an SFP slot. See Figure 12.
Figure 12. Removing the Dust Plug from an SFP Slot
3. Position the SFP transceiver with the label facing up.
