103

Chapter 7

Voice VLAN

This chapter contains a description of the AT-GS950/24 switch’s Voice

VLAN feature and the procedures to create, modify, and delete a voice

VLAN configuration. This chapter contains the following sections:

 “Overview” on page 104

 “General Guidelines” on page 107

 “Configuration” on page 108

 “OUI Setting” on page 111

Note

To permanently save your new settings or any changes to the

configuration file, select Save Configuration to Flash from the main

menu on the left side of the page.
