AT-GS950/24 Web Interface User Guide

319

Note

If the IP address contained in the new configuration file is different

than the one you currently have in your browser URL, you will loose

connectivity with the AT-S109 Version 1.1.0 Management software

on the

AT-GS950/24 switch after the new configuration file is loaded. If this

is the case, you can identify the new IP address by using the ATI

Web Discovery Tool. See“DHCP and ATI Web Discovery Tool” on

page 34 for more information.

3. The Results page will be displayed indicating that the file has been

successfully downloaded. See Figure 114.

Figure 114. Result Page

4. Click on the “Return to previous page” link.
