IV. Login
This chapter is mainly introducing Web- based UI after conneting the device.
First, check up the device’s IP address by connecting to DOS through the LAN PC under the device. Go to Start →
Run, enter cmd to commend DOS, and enter ipconfig for getting Default Gateway address, as the graphic below,
192.168.1.1. Make sure Default Gateway is also the default IP address of the router.
Attention!
When not getting IP address and default gateway by using “ipconfig”, or the received IP address is 0.0.0.0
and 169.X.X.X, we recommend that users should check if there is any problem with the circuits or the computer
network card is connected nicely.
