Allnet ALL-VPN10 User Manual

ALL-VPN10 VPN/Firewall WLAN-N WAN Router
© ALLNET GmbH München 2013 - All rights reserved
83
9.3 Smart QoS
The smart QoS function enables the administrators to constrain the bandwidth occupied automatically
without any configuring.
Enabled QoS：
Choose to apply QoS function.
When the usage of any WAN’s bandwidth is
over than___%, Enable Smart QoS
Input the required rate value into the column. The default
is 60%.
Each IP’s upstream bandwidth threshold (for all
WAN)：
Input the max. upstream rate for intranet IPs.
Each IP’s downstream bandwidth threshold
(for all WAN) ：
Input the max. downstream rate for intranet IPs.
If any IP’s bandwidth is over maximum
threshold, its maximum bandwidth will
remain：
When any IP uses more bandwidth than the above upstream
or downstream settings, the IP will be restricted for the
following upstream or downstream bandwidth settings.
Enabled Penalty Mechanism：
After choosing “Enabled Penalty Mechanism”, the device will
enable the penalty conditions internally. When the IP still
uses more upstream or downstream bandwidth than the
setting, the device will execute the penalty conditions
automatically.
Show Penalty IP：
The IPs which are under penalty mechanism will be shown
on the list.
