Product Assembly | AC-5000 User’s Manual
Product Assembly
Standard Configuration
Name of Components
Specification
Quantity
1 Binocular tube
Available in 180° variable-angle,
straight or 45° bevel.
1
2 Eyepiece
12.5X or 10X
2
3 Magnification pod
Five-range zooming
1
4 Objective lens
F250-430 Variable Objective Lens
optional: F300 large objective lens
1
5 Cross arm
Maximum radius of rotation is 870mm
1
6 Floor stand
Base diameter Φ550mm
1
7 Power adapter
Chinese standard, USA standard and
Europe standard are available for
option, subject to the order
1
8 HDMI high definition video
transmission wire
5m
1
9 U-disk (full electronic
instructions is saved in U-disk)
64G
1
10 Mouse
2.4G wireless mouse
1
