AC-5000 User’s Manual | Product Functions
Main Body Lens of Microscope
1 Lighting conversion turntable
Used to switch between different lighting modes where "W" represents the unfiltered
spot, "B" represents the blue filter, "G" represents the green filter, and "P" represents
the anti-glare mode.
2 Optical zoom knob
For manual adjustment of the optical magnification, and the numbers on the knob are
magnification factors.
3 Focusing knob
It is used for manually setting the image definition (focusing, working distance).
4 Locking screw
Used to loosen or lock a swivel ring so that the swivel ring can be rotated or locked.
