PA.04 Rating Current of Motor 1 Setting range : 0.1～999.9A [Based on Motor Type]
Notes:
 PA.01~PA.04 are used to set the parameters of the controlled motor 1. To ensure the control performance,
please do set relevant values correctly according to parameters on the motor nameplate.
 The motor power should match that of the inverter. Generally, the motor power is allowed to be 20% lower
than that of the inverter or 10% higher; otherwise, the control performance would not be ensured.
PA.05 No-load Current I0 of Motor 1 Setting range: 0.1~999.9A [Depending on model]
PA.06 Stator Resistance R1of Motor 1 Setting range:0.001~65.000Ω [Depending on model]
PA.07 Stator Leakage Inductance L1 of Motor
1
Setting range:0.1~2000.0mH [Depending on model]
PA.08 Rotor Resistance R2 of Motor 1 Setting range:0.001~65.000Ω [Depending on model]
PA.09 Mutual Inductive Impedance Lm of
Motor 1
Setting range:0.1~2000.0mH [Depending on model]
PA.10 Magnetic Saturation Coefficient 1of
Motor 1
Setting range:0.0%~100.0% [Depending on model]
PA.11 Magnetic Saturation Coefficient 2 of
Motor 1
Setting range:0.0%~100.0% [Depending on model]
PA.12 Magnetic Saturation Coefficient3 of
Motor 1
Setting range:0.0%~100.0% [Depending on model]
PA.13 Magnetic Saturation Coefficient 4 of
Motor 1
Setting range:0.0%~100.0% [Depending on model]
PA.14 Magnetic Saturation Coefficient 5 of
Motor 1
Setting range:0.0%~100.0% [Depending on model]
Notes:
If the motor parameters are unknown, please refer to the PA.29 motor parameters setting instruction. If they are
known, please write them down for PA.05~PA.09 correspondingly.
The motor magnetic saturation coefficients will be set automatically in the time of self-setting and doesn’t have to be
set by users.
PA.15Motor 2 pole number Setting range:2~56 [4]
PA.16Motor 2 rated power Setting range:0.4~999.9kW [Depending on model]
PA.17Motor 2 rated speed Setting range:0~24000r/min [Depending on model]
PA.18Motor 2 rated current Setting range:0.1~999.9A [Depending on model]
PA.19Motor 2 no-load current I0 Setting range:0.1~999.9A [Depending on model]
PA.20Motor 2 stator resistance R1 Setting range:0.001~65.000Ω [Depending on model]
PA.21Motor 2 stator leakage inductance L1 Setting range:0.1~2000.0mH [Depending on model]
PA.22Motor 2 rotor resistance R2 Setting range:0.001~65.000Ω [Depending on model]
PA.23Motor 2 mutual inductive reactance
Lm
Setting range:0.1~2000.0mH [Depending on model]
PA.24 Motor 2 magnetic saturation
coefficient 1
Setting range:0.0%~100.0% [Depending on model]
PA.25 Motor 2 magnetic saturation
coefficient 2
Setting range:0.0%~100.0% [Depending on model]
PA.26 Motor 2 magnetic saturation
coefficient 3
Setting range:0.0%~100.0% [Depending on model]
PA.27 Motor 2 magnetic saturation
coefficient 4
Setting range:0.0%~100.0% [Depending on model]
PA.28 Motor 2 magnetic saturation
coefficient 5
Setting range:0.0%~100.0% [Depending on model]
Notes:
